APX014
Global shutter Hybrid Vision Sensor for AI motion perception
High frame rate, low power, and global exposure hybrid vision sensor
APX014 is a high frame rate, low power, global-shutter Hybrid Vision sensor that supports image, event, hybrid and motion detection mode, with 1.3 MP image resolution, a 2.79 μm x 2.79 μm pixel size and a 1/4" optical size. As AlpsenTek's HVS sensor which enables global shutter, it greatly reduces exposure time, improves SNR and avoids the jelly effect caused by rolling shutter.
it high temporal resolution, low power and high dynamic range event sensing, accurately records movement trajectory enhances imaging quality. Combined with the HVS featured algorithms, APX014 is suitable for AI glasses/XR devices, robots, automotives, industrial applications and so forth, providing more competitive solutions for spatial intelligence and computing.
High temporal resolution
Pixel size
Low power modes
Low Power
Global shutter
High frame rate
Product Brief
EVS
- Low power EVS
- High dynamic range
- High sensitivity
APS
- Competitive image quality
- High frame rate
- Solid low light performance
Features
- 3D Stacking, BSl
- Supports EVS/APS/HVS/MD modes
- In-Pixel CDS
- Low noise
Functions
- HVS /APS only/EVS only
- LPMD on chip
- EVSMD on chip
- ALS
- LFR
Interface
- Date interface：MIPI CSI-2, D-PHY 1.2, 2 lanes 2.5 Gbps/lane, DVP
- Controlinterface：I²C
Applications
We provide multi-scenario solutions to help devices achieve smarter and more reliable perception and interaction.
Structured light
Detection and Tracking
Scan, measure and reconstruct
Obstacle avoidance/SLAM
End Products
We provide multi-scenario solutions to help terminal devices achieve smarter and more reliable perception and interaction.
XR headsets
Drones and robots
Automotive
Machine vision
Specification
*The specification are subject to the final product manual.Please contact us for more information if you are looking for a substaintial evaluation board for the innovative hybrid vision sensors
Resolution
APS: 1.3MP
EVS: 1.3MP
Hybrid-APS: 0.65MP, Hybrid-EVS:0.65MP
Pixel size
2.79μm × 2.79μm
Optical format
1/4"， CRA 25°
Operation mode
GS-APS / EVS / HVS / MD
EVS contrast sensitivity
0-100％ Configurable
Exposure mode
Global shutter
Minimal illumination
0.1 Iux
Dynamic range
APS: > 68dB
EVS: 120dB
ROI
Support APS/EVS mode
Operatin voltage
Analog: 3.0 V, 1.8V
Digital: 1.1V
I/O:1.8V
lmage data format
Raw8 / Raw10
Frame rate
APS: Full @ 120 FPS
EVS: Full @ 1000 FPS
Chip size
5.4 mm × 4.05 mm
Data Interface
MIPI, DVP, QSPI
Package
COB
Product Comparison
*Specifications may vary depending on the product version and application, and may change over time. Verification by the customer's technical experts is required for the specific application. Please contact us for more information.
APX003
APX003
APX002
APX004
Model
APX003
Chip Size
8.3mm × 6.9mm
Pixel Size
1.89μm × 1.89μm
Shutter Mode
Roller Shutter
Application
Smartphones / Security Cameras
Model
APX002
Chip Size
5.7mm × 6.1mm
Pixel Size
20 μm × 20μm
Shutter Mode
—
Application
Autonomous driving / Portable imaging devices
Model
APX004
Chip Size
10.7mm × 7.5mm
Pixel Size
2.88μm × 2.88μm
Shutter Mode
Roller Shutter
Application
Smart door locks / security cameras
Model Specifications
Model
Document
Contact Sales
Shutter Type(APS)
APS Resolution(MP)
EVS Resolution(MP)
Pixel Array
Pixel Size(μm)
Optical Size
CFA/Chroma
Max APS Frame Rate(FPS)
Max EVS Frame Rate(FPS)
APS DR(dB)
EVS DR(dB)
Data Interface
Global
1.3
1.3
1280Hx1024V
2.79 x 2.79
1/4"
MONO
Full @ 120
Full @ 1000
60
120
MIPI, DVP, QSPI
Rolling
4
1
APS: 2688H x 1520V
EVS: 1344H x 760V
3.15×3.15
1/1.64"
BAYER
Full @ 60
Full @ 500
68
120
MIPI, DVP,QSPI
Rolling
8
0.5
APS: 3264H×2448V
EVS: 816H x 612V
1.89 x 1.89
1/2"
RGBW
Full @ 30
Full @ 1000
60
100
MIPI
Rolling
8
0.5
APS: 3264H×2448V
EVS: 816H x 612V
1.89×1.89
1/2"
QBAYER
Full @ 30
Full @ 1000
60
100
