APX004
Hybrid Vision Sensor
Ultra-low power, fusion vision sensor with switchable output of image and event data
The ultra-low power APX004 is an innovative Hybrid Vision Sensor, supporting independentoutputs of image or event, or a millisecond-switch betweem them. By taking the uniqueHVS structure, as well as the 3D stacking and BSl processes, it operates in theultra-low-power event mode, and will switch to a 4MP image mode once it detects humanor motions, making it perfect for for AloT and security applications, especially for thoserequiring a long battery life.
Hi-Res
Pixel size
High SNR
Ultra-LP
High dynamic range
Fast Switch
Product Brief
EVS
- Ultra-low power
- On-chip motion detection
- High SNR
- High dynamic range
- High sensitivity
- Configurable contrast sensitivity
APS
- 4MP high-qualityimage
- Excellent low light performance
- Support HDR
Features
- 3D-stacked and BSl
- Image and event data outputs in parallelSupport independent operation of EVS
- 4MP image resolution
Functions
- lmage and event mode operate solely or parallelly
- Support HDR
- Support ROI (APS/EVS mode)
- Support on-chip motion detection
Interface
- Data interface：MIPI & DVP & QSPI
- Control interface：I²C & SPI
Applications
We provide multi-scenario solutions to help terminal devices achieve smarter and more reliable perception and interaction.
Security
Security cameras
AlOT
Smart lPCs
Automotive
ES, CMS, DMS, FCW
Consumer Electronics
Pc, tablet, TV
Machine Vision
Industrial automation
Medicine
Medical imaging
Specification
*The specification are subject to the final product manual.Please contact us for more information if you are looking for a substaintial evaluation board for the innovative hybrid vision sensors
Resolution
APS: 4MP
EVS: 0.45MP
Pixel size
2.88μm x 2.88μm
Optical format
1/1.8"， CRA 12°
Operation mode
APS / EVS / HVS / MD
Contrast sensitivity
0%-100％ configurable
Shutter mode
Rolling shutter
Min.illumination
< 0.05 lux
Frame rate
APS: 60 FPS @ Full Size
EVS: 500 FPS @ Full Size
Dynamic range
APS: > 70 dB
EVS: > 120 dB
ROI
APS / EVS support
Operating Voltage
Analog: 3.0 V
Digital: 1.1V
I/O: 1.8V
Power consumption
APS: 150 mW @ 30FPS, VGA
EVS: <10 mW @60FPS, Full Size
Data format
APS: Raw 8 / Raw 10 / Raw12
Output interface
MIPI, DVP, QSPI
Chip size
10.7mm X 7.5mm
Package
Fan-out
Product Comparison
*Specifications may vary depending on the product version and application, and may change over time. Verification by the customer's technical experts is required for the specific application. Please contact us for more information.
APX003
APX003
APX002
APX014
Model
APX003
Chip Size
8.3mm × 6.9mm
Pixel Size
1.89μm × 1.89μm
Shutter Mode
Roller Shutter
Application
Smartphones / Security Cameras
Model
APX002
Chip Size
5.7mm × 6.1mm
Pixel Size
20 μm × 20μm
Shutter Mode
—
Application
Autonomous driving / Portable imaging devices
