APX002
High cost-efficency EVS sensor
High cost-performance ratio, high frame rate, high dynamic range, low response latency, and computationally friendly.
APX002 is an high cost-effective event-based vision sensor (EVS) featuring high frame rate, wide dynamic range, low response latency, and computation-friendly architecture. With a pixel array of 256 x 256, 20 μm x 20 μm pixel size, and 1/4" optical format, it outperforms conventional solutions for applications demanding high efficiency and edge Al processing. ldeal for XR headsets (enabling precise eye-tracking and gesture recognition), AloT devices (on-device fall detection, presence monitoring, and anomaly recognition), and professional care solutions. It delivers enhanced privacy protection without full-image capture while reducing computational load and power consumption. This sensor enhances user experience through responsive, energy-efficient Al capabilities.
Resolution
Pixel Size
EVS Edge Al
Low Power
High Dynamic Range
High Frame Rate
Product Brief
EVS
- Low power EVS modes
- High dynamic range
- High frame rate
- High sensitivity
Features
- IN-PULSE DiADC architecture
- Compatible with main-stream low-power MCU/SoC
- Supports low power AON function
Functions
- Supports event-based vision sensing and outputs EVS signals
Interface
- Data interface: DVP
- Control interface: I²C
Applications
We provide multi-scenario solutions to help terminal devices achieve smarter and more reliable perception and interaction.
Eye tracking
Gesture recognition
Pose (Fall) detection
Presense monitoring
End Products
We provide multi-scenario solutions to help terminal devices achieve smarter and more reliable perception and interaction.
XR headsets
Edge AON Cameras
AlOT devices
Smart-care cameras
Specifications
*The specification are subject to the final product manual.Please contact us for more information if you are looking for a substaintial evaluation board for the innovative hybrid vision sensors
Resolution
256 × 256
Pixel size
20μm × 20μm
Optical format
1/4"， CRA 0°
Mode
EVS Mode
Contrast sensitivity
0-100％ configurabel
Min. illumination
0.1 Iux
Dynamic range
120 dB
Operating voltage
Analog: 1.2 V
Digital: 1.2V
Data format
EVS: Frame Mode
Data efficiency
EVS: 1000 FPS @ Full
Chip size
5.7 mm × 6.1 mm
Data interface
DVP
Power consumption
< 4mW @ 1000 FPS
Product Comparison
*Specifications may vary depending on the product version and application, and may change over time. Verification by the customer's technical experts is required for the specific application. Please contact us for more information.
APX003
APX003
APX004
APX014
Model
APX003
Chip Size
8.3mm × 6.9mm
Pixel Size
1.89μm × 1.89μm
Shutter Mode
Roller Shutter
Application
Smartphones / Security Cameras
Model
APX004
Chip Size
10.7mm × 7.5mm
Pixel Size
2.88μm × 2.88μm
Shutter Mode
Roller Shutter
Application
Smart door locks / security cameras
Model
APX014
Chip Size
5.4mm × 4.05mm
Pixel Size
2.79μm × 2.79μm
Shutter Mode
Global Exposure
Application
Scan / Measurement / Reconstruction
Model Specifications
Model
Document
Contact Sales
Shutter Type(APS)
APS Resolution(MP)
EVS Resolution(MP)
Pixel Array
Pixel Size(μm)
Optical Size
CFA/Chroma
Max APS Frame Rate(FPS)
Max EVS Frame Rate(FPS)
APS DR(dB)
EVS DR(dB)
Data Interface
Global
1.3
1.3
1280Hx1024V
2.79 x 2.79
1/4"
MONO
Full @ 120
Full @ 1000
60
120
MIPI, DVP, QSPI
Rolling
4
1
APS: 2688H x 1520V
EVS: 1344H x 760V
3.15×3.15
1/1.64"
BAYER
Full @ 60
Full @ 500
68
120
MIPI, DVP,QSPI
Rolling
8
0.5
APS: 3264H×2448V
EVS: 816H x 612V
1.89 x 1.89
1/2"
RGBW
Full @ 30
Full @ 1000
60
100
MIPI
Rolling
8
0.5
APS: 3264H×2448V
EVS: 816H x 612V
1.89×1.89
1/2"
QBAYER
Full @ 30
Full @ 1000
60
100
